What Is the NOMAD Handheld X-Ray?
The NOMAD is a portable, handheld X-ray device that lets dental professionals take intraoral radiographs at the patient's chair. It removes the need for a fixed wall-mounted X-ray tube or a dedicated X-ray room.
The device weighs roughly five to six pounds. It runs on a rechargeable battery and can produce dozens of images on a single charge. The operator holds it by a pistol-style grip, aims the cone at the tooth or area being imaged, and presses a trigger to expose the image.
NOMAD stands for a brand name manufactured by Aribex (now part of KaVo Kerr). Several similar handheld dental X-ray devices exist, but NOMAD was one of the first widely adopted models in the United States. When dentists refer to a "NOMAD X-ray," they typically mean any handheld intraoral radiography unit, much like people say "Kleenex" for tissues.
An oral and maxillofacial radiologist is a dental specialist trained in imaging technology, radiation safety, and image interpretation. These specialists can advise on when portable radiography is appropriate and how to read the resulting images accurately.
How Does the NOMAD Work?
The NOMAD generates X-rays using the same basic physics as a traditional wall-mounted dental X-ray unit. A small X-ray tube inside the device produces a focused beam of ionizing radiation that passes through oral tissues and onto a sensor or film.
The X-ray tube operates at approximately 60 kilovolts peak (kVp) and 2.5 milliamps (mA). These are standard energy settings for intraoral dental imaging. The exposure time for a single image is typically around 0.1 to 0.4 seconds, depending on the tooth location and patient size. The beam is collimated, meaning it is narrowed and directed through a cone so that only a small area of tissue is exposed.
What makes the NOMAD different from a wall-mounted unit is its shielding design. A circular backscatter shield sits between the cone and the operator's hand. This shield absorbs most of the radiation that bounces back (called backscatter) from the patient's tissues. Additional internal shielding inside the device housing protects the operator from leakage radiation.
The device works with both traditional phosphor storage plate (PSP) sensors and digital sensors. Digital sensors send the image directly to a computer screen within seconds. PSP plates require scanning but still produce a digital image. Either way, the resulting radiograph looks the same as one taken with a wall-mounted unit.
When Do Dentists Use a Handheld X-Ray?
Dentists use handheld X-rays whenever portable imaging is more practical or necessary than a fixed wall-mounted system. The clinical applications span general dentistry, oral surgery, and community outreach settings.
Emergency and Trauma Situations
In dental emergencies, speed matters. A handheld unit lets the dentist take an image without moving an injured patient to an X-ray room. This is especially useful in hospital emergency departments that may not have a dedicated dental X-ray setup.
Trauma cases often involve fractured teeth, displaced teeth, or jaw injuries. A quick periapical X-ray (an image showing the full length of a tooth and surrounding bone) taken at the bedside can help the clinician decide whether a tooth can be saved or needs extraction. The American Dental Association recognizes that radiographic examination is a standard part of evaluating dental trauma. [2]
Mobile and Community Dentistry
Mobile dental clinics, school screening programs, and nursing home visits often lack space for wall-mounted X-ray equipment. A handheld device fits in a carrying case and can be set up anywhere with minimal infrastructure.
Community health programs use portable X-rays to screen underserved populations for cavities, infections, and other conditions. The device allows a full diagnostic workup in settings where patients cannot easily travel to a dental office.
Surgical and Implant Settings
During oral surgery or dental implant placement, the surgeon sometimes needs a quick X-ray to check the position of an implant, verify root tip removal, or confirm that a fractured instrument is not left in the surgical site. A handheld unit provides immediate confirmation without breaking the sterile field or moving the patient.
Endodontists (root canal specialists) also use handheld X-rays during treatment. They may take multiple working-length films during a root canal to confirm that files are reaching the correct depth inside the canal. A chairside device speeds this process.
Patients with Limited Mobility
Some patients cannot sit upright in a standard dental chair or cannot be positioned in front of a wall-mounted unit. This includes wheelchair-bound patients, patients with severe gag reflexes who need quick exposures, and patients under sedation.
The handheld device can be angled and positioned to accommodate virtually any patient posture, making imaging more accessible for people with physical limitations.
FDA Status, Research, and Professional Positions
The NOMAD handheld X-ray device received FDA 510(k) clearance for intraoral dental radiography. FDA clearance means the device was reviewed and found to be substantially equivalent to a legally marketed device already on the market. This is different from FDA approval, which involves a more rigorous premarket review process typically reserved for higher-risk devices.
The distinction matters. FDA clearance confirms that the NOMAD meets baseline safety and performance standards for dental X-ray imaging. It does not mean the FDA tested the device independently or guaranteed a specific clinical outcome.
Research on handheld X-ray devices has generally shown that image quality is comparable to wall-mounted systems for intraoral periapical and bitewing radiographs. Several small studies have evaluated operator radiation exposure and found that the backscatter shield reduces dose to the operator's hands and body to levels well within occupational safety limits. However, large-scale randomized controlled trials comparing diagnostic accuracy between handheld and fixed units are limited in number.
Professional organizations such as the American Academy of Oral and Maxillofacial Radiology (AAOMR) provide guidance on radiation safety practices in dentistry. [1] The AAOMR's recommendations generally emphasize the ALARA principle (As Low As Reasonably Achievable), which means using the least amount of radiation necessary to get a diagnostic image. Handheld devices, when used according to manufacturer instructions, typically align with ALARA guidelines because they use collimated beams and standard exposure settings.
Benefits and Limitations of Handheld Dental X-Rays
Handheld dental X-rays offer clear advantages in specific situations, but they are not a universal replacement for wall-mounted systems. Here is an honest look at both sides.
Advantages
Portability is the most obvious benefit. The device goes wherever the patient is. This eliminates the need to transfer patients to an X-ray room, which saves time and reduces discomfort for patients with limited mobility.
Setup is minimal. There is no need for dedicated electrical wiring, wall mounting, or lead-lined rooms. A handheld unit can be deployed in minutes in any setting. For offices with small footprints or mobile clinics, this is a significant practical advantage.
The built-in backscatter shield means the operator does not need to leave the room or stand behind a barrier during exposure. This streamlines workflow, especially during surgical procedures or multi-image endodontic sequences where the clinician needs to stay chairside.
- Fully portable; fits in a carrying case
- Battery-powered; no wall outlet needed during exposures
- Operator stays at chairside, reducing procedural interruptions
- Works with standard digital sensors and PSP plates
- Useful in emergency departments, nursing homes, mobile clinics, and operating rooms
Limitations
The device weighs five to six pounds. Holding it steady for repeated exposures throughout a full clinical day can cause operator fatigue. This is a concern that does not apply to wall-mounted units, which are fixed in position.
Battery life limits the number of exposures per charge. In a high-volume practice taking dozens of X-rays per hour, a wall-mounted unit is more practical. The handheld device is better suited for situations where only a few images are needed at a time.
Some state dental boards have specific regulations about handheld X-ray use, including who may operate the device and what additional training or certification is required. Regulations vary, and not every jurisdiction permits all dental team members to use handheld units. Patients should be aware that their provider is following local rules.
Image quality is generally comparable to wall-mounted systems for standard periapical and bitewing images. However, for panoramic radiographs (wide images showing the entire jaw) or cone beam computed tomography (CBCT, a type of 3D dental scan), a handheld device cannot substitute. These advanced imaging modalities require separate, larger equipment.
- Heavier than it looks; operator fatigue is possible over a full day of use
- Battery limits the number of consecutive exposures
- Cannot replace panoramic or CBCT imaging
- State regulations vary on who can operate the device
- Limited large-scale studies comparing diagnostic accuracy to fixed systems
Cost and Insurance Coverage
For patients, the cost of an X-ray taken with a NOMAD is typically the same as one taken with a wall-mounted unit. Dental insurance and billing codes do not distinguish between the two. The procedure code covers the type of radiograph (periapical, bitewing, etc.), not the equipment used to take it.
Out-of-pocket costs for a single periapical X-ray typically range from $25 to $50 without insurance. A full-mouth series (usually 14 to 20 images) may range from $100 to $300. Costs vary by location, provider, and case complexity. Your insurance plan may cover diagnostic X-rays fully or partially, depending on your benefit structure and how recently your last radiographs were taken. [2]
The cost of the device itself is borne by the dental practice, not the patient. A NOMAD unit typically costs the practice several thousand dollars. This investment does not change what you are charged for the imaging service.
If you are seeking care from a mobile dental provider or community clinic that uses handheld X-rays, ask about accepted insurance plans and out-of-pocket fees before your visit. Payment structures at mobile and community settings sometimes differ from traditional private practices.
What to Ask Your Dentist About Handheld X-Rays
If your dentist uses a handheld X-ray device, you have every right to ask questions about safety and image quality. Most clinicians welcome these questions because informed patients tend to be more comfortable during procedures.
Here are specific questions worth asking before your imaging appointment.
- "Is this device FDA-cleared for the type of image you need?" (The answer should be yes for standard intraoral radiographs.)
- "How does the backscatter shield protect you while you hold the device?" (The clinician should explain the shielding and their radiation safety training.)
- "Will the image quality be the same as a wall-mounted X-ray?" (For periapical and bitewing images, it is typically comparable.)
- "How many images will you need, and what is each one for?" (This aligns with ALARA principles; each exposure should have a clinical reason. [1])
- "Does my state allow dental assistants to operate this device, or will the dentist take the image?" (Regulations vary by state.)
- "Will my insurance cover these X-rays the same way it covers traditional X-rays?" (In most cases, yes.)
Find an Oral and Maxillofacial Radiologist
If you have questions about dental imaging, radiation safety, or which type of X-ray is right for your situation, an oral and maxillofacial radiologist can help. These specialists complete additional years of training beyond dental school focused entirely on diagnostic imaging and interpretation. You can search for a specialist near you on the oral-radiology page at My Specialty Dentist.
