What Is a Dexis Digital X-Ray Sensor?
A Dexis digital sensor is a small electronic detector placed inside your mouth to capture dental X-ray images. It connects to a computer and displays the image on screen within seconds.
Traditional dental X-rays use film that must be exposed to radiation and then developed in chemical solutions. Digital sensors skip the chemical step entirely. Instead, they convert X-ray energy directly into an electronic signal that a computer translates into a visible image. This process is similar to how a digital camera replaces film photography.
Dexis is a brand name for a line of intraoral sensors manufactured by Dexis (now part of Envista Holdings). Several models exist, each designed to fit different areas of the mouth. The sensor itself is a rigid, rectangular wafer slightly thicker than a piece of film. It connects to a computer through a USB cable or wireless module.
Because the image appears on a monitor right away, your dentist can review findings with you during the same appointment. The digital file also becomes part of your electronic dental record, making it easy to compare images over time or share them with a specialist such as an oral radiologist.
How Digital X-Ray Sensors Work
Digital sensors use an electronic chip to detect X-ray photons and convert them into a digital image your dentist can view instantly.
Inside the sensor is a detector made from a material that responds to X-ray energy. Dexis sensors use a CMOS (complementary metal-oxide semiconductor) chip. When X-ray photons pass through your teeth and hit the chip, they create tiny electrical charges. The chip records the pattern of those charges, and software converts the pattern into a grayscale image on the computer screen.
The X-ray tube itself works the same way it does with film. It generates a brief pulse of X-ray radiation directed at the area of interest. The key difference is what catches the radiation on the other side of your teeth. Film captures it as a chemical reaction. A digital sensor captures it as an electronic signal. Because CMOS sensors are generally more sensitive to X-rays than older film types, the X-ray tube can often use a shorter exposure time or lower energy setting to produce a diagnostically useful image [2].
Once the image appears on screen, your dentist can use software tools to adjust it. Common adjustments include changing brightness and contrast, zooming into a specific tooth, inverting the image (swapping light and dark), and applying color filters that can highlight density differences. None of these adjustments add radiation. They simply reprocess the data the sensor already captured.
Basic Sensor Specifications
Dexis offers sensors in sizes comparable to standard dental film sizes. Size 1 sensors are designed for anterior (front) teeth, while Size 2 sensors cover posterior (back) teeth. The active imaging area, meaning the portion that actually captures the X-ray, is similar in dimension to the corresponding film size.
Resolution is measured in line pairs per millimeter (lp/mm). Higher numbers mean finer detail. Dexis sensors typically offer resolution in a range that meets or exceeds the diagnostic needs for detecting cavities, bone loss, and other common dental conditions. The practical image quality also depends on proper positioning, exposure settings, and software processing.
What Digital X-Ray Sensors Are Used For
Dentists use digital intraoral sensors for the same diagnostic tasks that once required film X-rays, from finding cavities to planning implants.
Detecting Cavities and Tooth Decay
Bitewing X-rays are the most common images taken with intraoral sensors. You bite down on a small tab attached to the sensor while the X-ray is taken. The resulting image shows the crowns of your upper and lower teeth and the bone between them. Dentists look for dark spots between teeth that may indicate decay not yet visible to the eye.
Digital enhancement tools can make subtle areas of early decay easier to spot. Your dentist might adjust the contrast or zoom into a suspicious area, potentially catching a small cavity before it becomes a larger problem [2].
Evaluating Bone and Gum Health
Periapical X-rays show the entire tooth from crown to root tip, including the surrounding bone. These images help dentists evaluate bone levels around each tooth. Bone loss is a hallmark of periodontal disease (gum disease). Digital sensors allow precise side-by-side comparisons of images taken months or years apart, helping track whether bone levels are stable or declining.
The American Dental Association recommends that the frequency of dental X-rays be based on individual risk factors rather than a fixed schedule [2]. Patients with active gum disease may need imaging more often than patients with healthy bone levels.
Root Canal Treatment and Implant Planning
During root canal therapy, periapical images taken with a digital sensor help the dentist measure canal length, check the position of instruments inside the canal, and confirm that the filling material reaches the correct depth. The instant image display is especially useful here because multiple images may be needed during a single procedure.
For dental implant planning, periapical and bitewing images provide information about bone height and the location of neighboring tooth roots. More complex cases may also require three-dimensional imaging such as cone beam CT, but intraoral digital sensors remain valuable for baseline assessment and follow-up.
Pediatric Dentistry and Orthodontics
Children benefit from reduced radiation exposure because developing tissues are more sensitive to radiation than adult tissues [1]. Digital sensors help keep doses low while still providing the images needed to monitor tooth development, check for missing or extra teeth, and plan orthodontic treatment. Smaller sensor sizes (Size 0 and Size 1) fit more comfortably in a child's mouth.
Evidence, FDA Status, and Professional Guidance
Dexis digital sensors are FDA-cleared Class II medical devices, meaning they have been reviewed for safety and effectiveness for dental diagnostic imaging.
It is important to distinguish between FDA clearance and FDA approval. Clearance (through the 510(k) pathway) means the manufacturer demonstrated that the device is substantially equivalent to a legally marketed device already in use. Approval (through the premarket approval pathway) involves a more rigorous review typically required for higher-risk devices. Most intraoral dental sensors, including Dexis models, reach the market through the 510(k) clearance process.
The American Academy of Oral and Maxillofacial Radiology (AAOMR) supports the use of digital imaging in dentistry and has published guidance on selection criteria for dental radiographs [1]. The American Dental Association also provides patient-facing resources explaining how digital X-rays work and the rationale for radiation dose reduction [2].
Published literature comparing digital sensors to film generally shows that digital systems can achieve diagnostic accuracy comparable to film for common tasks like caries (cavity) detection, while using lower radiation doses. However, results vary across studies depending on the specific sensor model, exposure parameters, and clinical conditions being evaluated. Clinicians are encouraged to follow the ALARA principle, which stands for "As Low As Reasonably Achievable," meaning they should use the lowest radiation dose that still produces a diagnostically useful image [1].
Benefits and Limitations
Digital sensors offer real advantages over film, but they also come with trade-offs that are worth understanding.
Advantages of Digital Sensors
Reduced radiation exposure is one of the most frequently cited benefits. Digital sensors are generally more sensitive to X-rays than conventional D-speed film, which means shorter exposure times are often sufficient. The exact reduction depends on the sensor, the film it is being compared to, and the clinical settings used. Comparisons to faster E/F-speed film show a smaller difference than comparisons to older D-speed film [2].
Speed is another clear advantage. Images appear on screen in seconds. There is no darkroom, no chemical processing, and no waiting. This saves time during procedures like root canals where multiple images are taken in sequence.
Environmental benefits exist as well. Film processing requires chemical solutions (developer and fixer) that contain hazardous materials and must be disposed of properly. Digital imaging eliminates this waste stream entirely.
Long-term storage and sharing are simpler with digital files. Images can be sent electronically to a specialist, an insurance company, or a new dental office. They do not fade or degrade over time the way film can.
- Lower radiation dose compared to conventional film in many clinical scenarios
- Instant image display with no chemical processing delay
- Software enhancement tools improve diagnostic interpretation without additional exposure
- Easy sharing with specialists, insurers, and patients
- No chemical waste from film processing
Limitations to Be Aware Of
Sensor rigidity is the most common patient complaint. Film is thin and flexible. Digital sensors are thicker and rigid, which can be uncomfortable, especially in smaller mouths or when imaging the back teeth. Some patients with a strong gag reflex find sensors harder to tolerate than film.
The sensor cable (on wired models) can also feel awkward. Wireless sensors eliminate the cable but may be slightly thicker. Positioning the sensor correctly is essential for a diagnostic image, and the rigid shape sometimes makes ideal positioning more difficult.
Cost of the equipment is significant for the dental practice. A single sensor can cost several thousand dollars, and the associated software and computer hardware add to the investment. If a sensor is dropped or bitten through its protective sleeve, it can be damaged. These costs may indirectly affect practice overhead, though they do not typically change what a patient pays per X-ray.
Image quality depends on proper technique. An improperly positioned sensor or incorrect exposure setting can produce a non-diagnostic image, requiring a retake and additional radiation. This is true of film as well, but the learning curve for sensor placement can be slightly steeper for dental teams transitioning from film.
Cost and Insurance Coverage
For patients, the out-of-pocket cost of a digital X-ray is typically similar to what a film X-ray would cost. The technology difference is behind the scenes.
Dental insurance plans generally cover diagnostic X-rays based on the type of image (bitewing, periapical, full mouth series) rather than whether film or digital technology was used. The CDT (Current Dental Terminology) billing codes are the same for both. Most plans cover bitewing X-rays once every 6 to 12 months and a full mouth series every 3 to 5 years, depending on the plan and the patient's risk level [2].
Without insurance, the cost of a single periapical or bitewing digital X-ray typically falls in the range of $25 to $50 per image. A full mouth series (usually 14 to 20 images) may range from $150 to $350. Costs vary by location, provider, and case complexity. These ranges are general estimates and can differ significantly based on geographic area and practice type.
The majority of dental practices in the United States have transitioned to digital radiography. You are likely to encounter a digital sensor or a phosphor plate system (a different type of digital imaging) at most general dental offices and specialist practices today.
What to Ask Your Dentist About Digital X-Rays
You have every right to ask about the imaging technology used in your care and how radiation exposure is managed.
Here are specific questions worth asking at your next dental visit. These questions help you understand your individual situation and show your dentist that you are an engaged partner in your care.
- What type of digital sensor do you use? This helps you understand whether the practice uses a direct sensor (like Dexis), a phosphor plate, or film.
- How do you determine how often I need X-rays? The answer should reference your individual risk factors, not just a calendar schedule [2].
- What steps do you take to minimize my radiation dose? Look for mentions of the ALARA principle, rectangular collimation (a device that narrows the X-ray beam), and thyroid collars or lead aprons when appropriate [1].
- Can I see my X-rays on screen? Digital imaging makes it easy for your dentist to walk you through findings on a monitor.
- Will my images be shared with a specialist if needed? Digital files transfer easily, which can save you from needing repeat images at a specialist's office.
- Do you have a radiation safety protocol for children or pregnant patients? This is especially relevant if you are scheduling imaging for a child or if you are pregnant.
Find a Dental Imaging Specialist
If you need advanced imaging interpretation or have concerns about a dental X-ray finding, an oral and maxillofacial radiologist can help. These specialists focus on diagnostic imaging of the teeth, jaws, and surrounding structures. You can search for an oral radiologist in your area on the oral-radiology page to find a qualified provider near you.
